• JD 100 MKII Pro

    Vacuum Tube Compact Disc Player

  • Design & Details

  • Technical Specification

    Tube Complement: 12AU7 2Pcs,6922 1Pcs

    Signal Output

       -Analog: RCA a set, XLR a set

       -Digital: Optical*1, Coaxial*1

    Audio output level

       RCA: 3.2Vrms

       XLR: 1.8Vrms:

    Frequency Response: 17Hz--20KHz (+-0.1dB), 1KHz 0dB

    Distortion THD+N: 0.01% at 1 KHz

    Noise and Hum: 96dB(A weighting)

    Dynamic Range:96dB

    Power Requirements: AC99-120AC0/60Hz, AC198-AC240/50Hz

    Dimensions: By 17.1 inches (43.4cm) wide By 13.7inches (34.8cm) deep By 3.5 inches (8.8cm) high

    Weight: 27.6pounds (12.5Kg) Net
